VCDS Tweaks.

[Deaky]

Hello.
Byte 07 Bit 3 Remote Control inactive - I can control (open-close doors) the key buttons when the engine is running, right? thank u

Remote control inactive stops you from locking or unlocking the van with the buttons on the keyfob



[Deaky]

Byte 2 bit 2 Remote control with terminal 15 is the one you want



[MULT6]

Thank you!!

do i need access code before changing? 09-Cent. Elect. - 31347 or 20107



[Deaky]

Thank you!!

do i need access code before changing? 09-Cent. Elect. - 31347 or 20107

Nope



[MULT6]

Deaky, thank u!
I activated the key buttons and closing the doors after 15 km/h.
Can you tell by headlight washers and setting their work?



[Lez78]

Who has this option in the Assist menu?



[Robert]

I'm afraid this feature is not available on T6.



[Lez78]

I'm afraid this feature is not available on T6.

That is a T6 speedo 7E0 920 880 S



[Robert]

Is this your instrument cluster?



[Lez78]

was on eBay...
I have 7E0 920 980 S (UK ver)
VW T6 3D Premium Tacho 7E0920880S 7E0920880 S H04 SW 1109 | eBay



[Robert]

Who has this option in the Assist menu?View attachment 54768

This is rear traffic alert that comes as addition to Side Assis(Lane departure warning) on some new VAG vehicles.
Have a look here.



[Robert]

was on eBay...
I have 7E0 920 980 S (UK ver)
VW T6 3D Premium Tacho 7E0920880S 7E0920880 S H04 SW 1109 | eBay

Listing description reads as follows:

You are bidding on your 3D speedometer 7E0920880S / H04 / SW1109 see pictures. In each case left and right various LEDs without function, therefore declared as defective.

As always with private, no guarantee or return, and now have fun bidding



[Salty Spuds]

This is why you should always reverse park, especially in a van.



[Robert]

I am suggesting this location for further discussion on this matter ----> Side Assist - To Retrofit Or Not To Retrofit



[Lez78]

I know... You need Park Pilot and Side Assist for it...
I just wondering how that possible on a T6 speedo as a menu for it



[Robert]

You don't know what else was connected to that unit when this photo was taken. In most cases of this kind, centre LCD serves as a "display unit" for CAN gateway.



[dnoermann]

Who has this option in the Assist menu?View attachment 54768

Cool
Since the Firmware is VW-Generic this feature is available in probably all T6 Speedos.
I looked into the Firmware of my 720920970S SW 1104 and found it too:.

001ABEB0 3A CA 51 03 41 75 73 70 61 72 6B C8 54 02 73 74 :...Auspark...st

001ABF50 79 6A 61 7A 64 75 2F C9 E1 00 6E B8 76 2E 61 73 yjazdu/...n.v.as
001ABF60 73 2F D2 B2 04 D0 03 00 54 72 61 69 6C 65 72 3A s/Ҳ ....Trailer:

001B15C0 74 61 D5 C5 00 42 6C 69 6E 64 20 53 70 6F 74 20 ta...Blind Spot

So the Speedo can do it.
You now need to retrofit the correct ECU with Radar Sensor on the side for it to work.
And probably you need to do some stuff more ...
Lets find it out



[SAF1981]

OK and what is a VCDS user and the mumbo jumbo code wording that's so obvious to everyone else

Ah just googled VCDS, an expensive tweaking gadget my wife would use to tweak me around the head if I bought one



[Robert]

...
001ABF50 79 6A 61 7A 64 75 2F C9 E1 00 6E B8 76 2E 61 73 yjazdu
....

This one intrigues me, especially description "yjazdu".
Cause in Polish there is a word WYJAZDU which actually would be description for RTA



[Ads_Essex]

This one intrigues me, especially description "yjazdu".
Cause in Polish there is a word WYJAZDU which actually would be description for RTA

Which reminds me.. a colleague asked if we could stop so he could have a photo taken:

Anyway. I digress. As you were..
